- GB.9-V1 -
BAD & REPLACE
××.××V ×××× SAE
BAD CELL & REPLACE
××.××V ×××× SAE
LOAD ERROR
PRINT RESULT? ◄►
↵
NO
PRINT 24V SYSTEM
RESULT? YES
BAD & REPLACE :
The battery will not hold a
charge. It should be replaced
immediately.
BAD CELL & REPLACE :
The battery has at least one
cell short circuit. It should be
replaced immediately.
LOAD ERROR :
The tested battery is bigger
than 2000CCA or 200AH. Or
the clamps are not connected properly. Please fully
charge the battery and retest after excluding both
previous reasons. If reading is the same, the battery
should be replaced immediately.
12.
Press the ◄ ► key to select
result printing: YES or NO.
Press «ENTER» to confirm
your choice.
※ 24V System Test Printing:
T
he
printer
will
not
function
for
24
Volt
batteries
system
test printing. The 24V system
test result will be recorded till you hook up to a
12V battery and the right screen shows up. Please
select “YES” and press enter key to print the result
and then disconnect the clamps. The screen will
appear again after you reconnect the clamps.
Please select “NO” and press the enter key to go
back to the main menu.
13.
Press «ENTER» return to step 5 or remove the test
clamps from the battery posts after completion of testing
batteries to end test.
