Powering the ICP Module &
Calibrating to the Patient Monitor
Patient monitor will read >250 mmHg
until ICP Sensor is zeroed and active
Connect DirectLink® ICP Module to the
bedside Patient Monitor (PM). Panel lights
will flash in sequence during self-test.
Wait for SOLID AMBER status light before
continuing.
Press ARROW BUTTON until the 0 mmHg
reference signal indicator illuminates.
Zero patient monitor per manufacturer’s
instructions.
Press ARROW BUTTON until the 100 mmHg
reference signal indicator is illuminated.
Check that the value displayed on the patient
bedside monitor is 100.
Exit calibration mode by pressing ARROW
BUTTON until neither green reference signal
indicator is lit and status light is SOLID
AMBER.
2
PATIENT MONITOR SETUP
