Integra Codman DirectLink User Manual

SOLID RED LIGHT – MODULE ERROR DETECTED
RESET PROCEDURE: Any time the red status
light illuminates, the Module must be RESET by
disconnecting power. Unplug cable from patient
monitor and reconnect to reset.
If error occurs during...
SELF-TEST: RESET to try again. If problem persists,
patient monitor may be incompatible or DirectLink ICP
Module needs to be replaced.
DURING USE: A damaged cable or sensor may have
been detected.
1) Disconnect all cables & sensor and RESET module.
2) Reconnect ICP Extension Cable; if error returns,
replace extension cable and RESET.
3) Reconnect sensor; if error returns, replace sensor
and RESET.
4) If problem persists, replace DirectLink ICP Module.
5
TROUBLESHOOTING
