MGD-33 DVD MECHANISM PARTS LIST RDV-1.1
ONKYO Q'TY
Item Part No. Description Material pcs
1-a 24802052 CHASSIS ABS T250(B)
(1)
1-b 24828039 SHAFT(A)
SUS420J2 D3.15
(1)
1-c 24828040 SHAFT(B)
SUS420J2 D3.15
(1)
1 A10-3322 CHASSIS AS
1
2 24810094 GEAR(CARRIER) POM M90-44(N) 1
3 24810095 GEAR IDLER POM LA-531(N) 2
4 24810096 GEAR(MAIN) POM M90-44(B) 1
5 24802055 A SUB CHASSIS(FRAME T) ABS T250(B) 1
6 24802057 TRAY ABS 450 (B) 1
7 24810092 GEAR(CENTER) POM M90-44(N) 1
8 24840164-1 SLIDER POM TR-20(B) 1
9 24826030 RETAINER(L) POM TR-20(B) 1
10 24810093 GEAR(PULLEY) TPE 6333N 1
11 24826031 A RETAINER(R) POM TR-20(B) 1
12 24810091 MOTOR PULLEY POM M90-44(B) 1
13 24802054-1 SUB CHASSIS(CLAMP) A5052P t1.5 1
14 24840163 SLIDER POM TR-5(B) 1
15 24824006-1 CAP(CHC) POM M90-44(B) 1
16 24828041 ROD (GUIDE) H SUS420J2 D3.15 1
17 24828043 SHAFT (TRAY R) H SUS420J2 D4.15 1
18 24828042 SHAFT(TRAY L) H SUS420J2 D4.15 1
20 801593 BIND TAP TITE(P)SC M2.6*8 ETO 8
21 24834044 FLAT WSHR 2.6*4.7*0.5 CUT ETO 2
22 801596 SCREW 2.6*6 SWCH 16A ETO 3
23 801610 FLAT TAP TITE SCREW 2.6*6 ETO 2
24 24816040 BELT YAMAUCHI 1
26 24836043 NON WOVEN FABRIC NISSHO 1
27 24830004-1 YOKE(CHB) CHEONGWAH 1
28 24832006-1 MAGNET(CHB) JINBAO 1
29 24840169 MIRROR TAPE --- 3
30 24834049 WASHER ETO 1
31 28141581 SHEET NISSHO 1
32 24840166 WIRING HARNESS SAKURA 1
33 24834050 A SPACER --- 1
34 24804048 DC MOTOR MSN5G543C PSI 1
35 24840167 DETECT SWITCH SSS23 SHINMEI 1
