Intel 865 User Manual

-One PS/2 mouse port
-One GAME/MIDI port
-One VGA port
-One IRDA port
-Two SATA ports
-Sound onboard AC’97 2.2 specification compliant
Supports six channel sound input (example Realtek ALC650)
Supports 16 bit ADC (Analog Digital Converter)
Supports multiple stereo input mixer
Provides Mic In Line In Line Out jack
-Built-in 10/100 Mbps LAN card (Optional)
-Expansion slot:
One 4X/8X AGP slot (supports 1.5V only)
Two 32-bit PCI slots 2.2 specifications compliant
-Dimension
Micro ATX form factor
Chapter 4 Installation
4.1 Jumper Setting and Slot
FSO/FS1: CPU Frequency Jumper setting
Jumper AUTO (Default) 400 533 800
FSO 1-2 2-3 OPEN 2-3
FS1 1-2 2-3 2-3 OPEN
Jp6: Clear CMOS Jumper setting
1-2 (Default) Normal
2-3 Clear CMOS
Audio: Front panel Jumper setting
PIN Function PIN Function
1 MIC+ 2 Ground
3 Vbias 4 AuD_Vcc(AVCC)
5 AuD_R_Out 6 R_Out Back
7 N.C 8 Key
