Intel 865 User Manual

9 AuJF_L_Out 10 L_Out Back
SATA: PIN Jumper setting
PIN SATA Function PIN SATA2 Function
1 Ground 1 Ground
2 RSATA_RXP1 2 RSATA_RXP2
3 RSATA_RXNI 3 RSATA_RXN2
4 Ground 4 Ground
5 RSATA_TXP1 5 RSATA_TXP2
6 RSATA_TXP1 6 RSATA_TXP2
7 Ground 7 Ground
Expansion slot
DDR1/DDR2 184PIN DDR MEMORY SLOT
PCI1/PCI2 32 PIN PCI BUS expansion slots
AGP8X AGP display expansion slots
Socket 775 Socket 775 CPU slots
USB: Expansion Connector
PIN Function PIN Function
1 VCC: Power 2 VCC: Power
3 D-: DATA-Signals 4 D-: DATA –Signal
5 D+: DATA +Signal 6 D+: DATA + Signals
7 GND: Ground 8 GND: Ground
9 Key 10 NC
Connectors
PS/2 (Bottom) PS/2 keyboard (Purple)
PS/2 (Top) PS/2 Mouse header (Green)
USB1/2/Lan USB ½ LAN Connector port
USB3/4 USB3/4 Connector Port
USB5/6 USB 5/6 Connector Port
USB7/8 USB7/8 Connector port
LPT Pinter Connector port
COM1/com2 Serial port COM1/COM@ connector port
GAME/MIDI GAME/MIDI Port
LINE OUT/LINE IN/MIC Audio Output/Audio
Input/Microphone
CD_IN CDROM Audio Input port
