Intel BLKDH61WWB3 User Manual

Intel Desktop Board DH61WW Technical Product Specification
14
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Descript
ion
A Conventional PCI bus add-in card connector
B Chassis intrusion header
C S/PDIF header
D PCI Express x1 add-in card connector
E Battery
F PCI Express x16 add-in card connector
G Back panel connectors
H Standby power LED
I 12 V internal power connector (ATX12V)
J Rear chassis fan header
K Piezoelectric speaker
L LGA1155 processor socket
M Processor fan header
N Low Pin Count (LPC) Debug header
O DIMM 1 (Channel A DIMM 1)
P DIMM 2 (Channel B DIMM 1)
Q Trusted Platform Module (TPM) header
R Main power connector (2 x 12)
S SATA connectors
T BIOS setup configuration jumper block
U Front panel header
V Intel H61 Express Chipset
W Serial port header
X Front panel USB 2.0 headers
Y Front panel audio header

Intel BLKDH61WWB3 Specifications

General

Brand	Intel
Model	BLKDH61WWB3
Category	Motherboard
Language	English
