Table 10. Component-side Connectors and Headers Shown in Figure 10
Item/callout
from Figure 10 Descript
ion
A Conventional PCI bus add-in card connector
B Chassis intrusion header
C S/PDIF header
D PCI Express x1 add-in card connector
E PCI Express x16 bus add-in card connector
F 12 V internal power connector (ATX12V)
G Rear chassis fan header
H Processor fan header
I LPC Debug header
J TPM header
K Main power connector (2 x 12)
L SATA connectors
M Front panel header
N Serial port header
O Front panel USB 2.0 header
P Front panel audio header
