Intel D525MW Specification

Intel Desktop Board D525MW and Intel Desktop Board D525MWV Specification Update 5
Terminology
Specification Changes are modifications to the current published specifications.
These changes will be incorporated in the next release of the specifications.
Errata are design defects or errors. Characterized errata may cause the desktop
board behavior to deviate from published specifications. Hardware and software
designed to be used with any given Altered Assembly (AA) and BIOS revision level
must assume that all errata documented for that AA and BIOS revision level are
present on all desktop boards.
Specification Clarifications describe a specification in greater detail or further
highlight a specification’s impact to a complex design situation. These clarifications
will be incorporated in the next release of the specifications.
Documentation Changes include typos, errors, or omissions from the current
published specifications. These changes will be incorporated in the next release of the
specifications.
General Information
Basic Desktop Board D525MW and D525MWV Identification Information
AA Revision BIOS Revision Notes
E93082-300 MWPNT10N.86A.0049 1,2
E93080-300 MWPNT10N.86A.0049 1,2
E93082-301 MWPNT10N.86A.0069 1,2
E93081-301 MWPNT10N.86A.0069 1,2
E93080-301 MWPNT10N.86A.0069 1,2
E93080-400 MWPNT10N.86A.0069 1,2
E93081-400 MWPNT10N.86A.0069 1,2
E93082-400 MWPNT10N.86A.0069 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The Intel
®
CG82NM10 Express Chipset used on this AA revision consists of the following component:
Device Stepping S-Spec Numbers
CG82NM10 B0 SLGXX

Intel D525MW Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Single-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	4 GB
Supported memory clock speeds	800, 1066 MHz
Product family	Desktop board
Product series	Intel® Desktop Boards with Intel Atom® Processors
Processor socket	-
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	8
Parallel ports quantity	1
Market segment	Desktop
Power source type	ATX
Motherboard chipset	Intel® NM10 Express
Audio output channels	5.1 channels
Motherboard chipset ID	47610
Motherboard form factor	mini ITX
Motherboard chipset family	Intel
Compatible operating systems	Windows XP, Vista, 7
Parallel processing technology support	Not supported
Networking features	10/100/1000
Audio channels	6
Graphics output	VGA
Motherboard ARK ID	48952
Discrete graphics card model	None
Commodity Classification Automated Tracking System (CCATS)	NA
Status	Discontinued
Form factor	Mini-ITX
Last change	63903513
Launch date	Q4'10
USB ports quantity	7
Sustainability certificates	ENERGY STAR
Supported RAID configuration	N/A
Harmonized System (HS) code	8471500150
