Intel D945GCLF - Desktop Board Essential Series Motherboard User Manual

6 Intel Desktop Board D945GCLF Specification Update
General Information
Basic Desktop Board D945GCLF Identification Information
AA Revision BIOS Revision Notes
E27042-301 LF94510J.86A.0038 1,2
E27042-302 LF94510J.86A.0038 1,2
E27042-303 LF94510J.86A.0038 1,2
E27042-304 LF94510J.86A.0038 1,2
E27042-305 LF94510J.86A.0067 1,2
E27042-400 LF94510J.86A.0099 1,2
E27042-401 LF94510J.86A.0099 1,2
E27042-402 LF94510J.86A.0099 1,2
E27042-403 LF94510J.86A.0140 1,2
E27042-404 LF94510J.86A.0140 1,2
E27042-405 LF94510J.86A.0171 1,2
E27042-406 LF94510J.86A.0182 1,2
E27042-407 LF94510J.86A.0229 1,2
E27042-408 LF94510J.86A.0229 1,2
E27044-303 LF94510J.86A.0038 1,2
E27044-304 LF94510J.86A.0038 1,2
E27044-305 LF94510J.86A.0038 1,2
E27044-306 LF94510J.86A.0038 1,2
E27044-307 LF94510J.86A.0067 1,2
E27044-400 LF94510J.86A.0099 1,2
E27044-401 LF94510J.86A.0099 1,2
E27044-402 LF94510J.86A.0099 1,2
E27044-403 LF94510J.86A.0140 1,2
E27044-404 LF94510J.86A.0140 1,2
E27044-405 LF94510J.86A.0171 1,2
E27044-406 LF94510J.86A.0182 1,2
E27044-407 LF94510J.86A.0229 1,2
E27044-408 LF94510J.86A.0229 1,2
Notes:
1. The AA number is found on a small label on the component side of the board.
2. The 945 Chipset kit used on this AA revision consists of two components as follows:
Device Stepping S-Spec Numbers
82945GC A2 SLA9C
82801GB A1 SL8FX

Intel D945GCLF - Desktop Board Essential Series Motherboard Specifications

General

Form Factor	Mini-ITX
Memory Type	DDR2 SDRAM
Maximum Memory	2 GB
Graphics	Intel Graphics Media Accelerator 950
Expansion Slots	1 x PCI
USB Ports	8 x USB 2.0
RAM Technology	DDR2 SDRAM
Supported RAM Integrity Check	Non-ECC
Compliant Standards	RoHS
PS/2 Ports	1 x keyboard, 1 x mouse
Serial Ports	1
Parallel Ports	1
Chipset	Intel 945GC Express
Audio	Realtek ALC662
LAN	10/100 Mbit/s
Storage Interface	2 x SATA 3Gb/s
RAM Slots	2 x DIMM 240-pin
Network Interfaces	1 x Ethernet 10/100 Mbps
USB Ports Configuration	4 x USB 2.0 (rear)
Interfaces	1 x VGA, 1 x LAN, 4 x USB 2.0
Internal Interfaces	1 x floppy
Power Connectors	1 x 24-pin ATX
Memory Slots	2 x DIMM 240-pin
Storage	2 x SATA 3.0 Gb/s
