Intel Desktop Board DG35EC Product Guide
12
Table 2. Desktop Board DG35EC Components
Label Description
A PCI bus connector
B IEEE 1394a header
C PCI Express x1 connector 2
D Speaker
E PCI Express x1 connector 1
F PCI Express x16 connector
G Rear chassis fan header (3-pin)
H Back panel connectors
I 12 V processor core voltage connector (2 x 2 pin)
J Processor socket
K Processor fan header (4-pin)
L DDR2 DIMM 0 sockets
M DDR2 DIMM 1 sockets
N Front chassis fan header (3-pin)
O Serial header
P Diskette drive connector
Q Main power connector (2 x 12 pin)
R IDE connector
S Chassis intrusion header
T Serial ATA connectors (4)
U Front panel header
V Alternate front panel power LED header
W High-speed USB 2.0 headers (2)
X BIOS configuration jumper block
Y Battery
Z S/PDIF connector
AA Front panel audio header
Go to the following locations for more information about:
• Desktop Board DG35EC
http://www.intel.com/design/motherbd
• Supported processors
http://www.intel.com/go/findCPU
