Intel Desktop Board DH61CR Technical Product Specification
12
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• Ten USB ports:
― Four USB 2.0 ports are implemented with stacked back panel connectors
― Six USB 2.0 front panel ports are implemented through three dual-port
internal headers
• Four SATA interfaces through the Intel H61 Express Chipset
• One serial port header
• One parallel port connector on the back panel
• One PS/2* keyboard/mouse port on back panel
Legacy I/O Control
•
Nuvoton* W83677HG-i Super I/O controller for hardware management and
serial port, parallel port, and PS/2 support
BIOS
•
Intel
®
BIOS resident in the SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI), Plug and
Play, and SMBIOS
Instantly Available
PC Technology
• Support for PCI* Local Bus Specification Revision 2.2
• Support for PCI Express*
• Suspend to RAM support
• Wake on Conventional PCI, PCI Express, LAN, front panel, serial, PS/2, and
USB ports
LAN Support Gigabit (10/100/1000 Mbits/s) LAN subsystem using the Intel
®
82579V Gigabit
Ethernet Controller
Expansion
Capabilities
•
One PCI Express 2.0 x16 add-in card connector
• Two PCI Express 2.0 x1 add-in card connectors
• One Conventional PCI bus connector
Hardware Monitor
Subsystem
• Hardware monitoring through the Nuvoton Super I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers
• Two fan sense inputs used to monitor fan activity
• Fan speed control
