Intel Desktop Board DH61CR Technical Product Specification
22
1.10 Legacy I/O Controller
The Legacy I/O Controller provides the following features:
• One serial port
• One back panel parallel port (with Extended Capabilities Port (ECP) and Enhanced
Parallel Port (EPP) support
• PS/2-style keyboard/mouse interface on the back panel
• Serial IRQ interface compatible with serialized IRQ support for PCI Conventional
bus systems
• Intelligent power management, including a programmable wake-up event interface
• Conventional PCI bus power management support
The BIOS Setup program provides configuration options for the Legacy I/O controller.
1.10.1 Serial Port
The serial port is implemented as a 10-pin header on the board. The serial port
supports data transfers at speeds up to 115.2 kbits/s with BIOS support.
For information about Refer to
The location of the serial port header Figure 10, page 43

Intel DH61CR Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	2
Max Memory	16 GB
Memory Standard	DDR3 1066/1333
PCIe x16 Slots	1
PCIe x1 Slots	2
PCI Slots	1
RAID Support	No
SATA Ports	4 x SATA 3Gb/s
USB Ports	4 x USB 2.0
VGA	1 x VGA
DVI	Yes
