Intel Desktop Board DH61DL Product Guide
10
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• Two USB 3.0 ports (blue) are implemented with stacked back panel
connectors
• Eight USB 2.0 ports (black):
― Two USB 2.0 ports are implemented with stacked back panel
connectors
― Six USB 2.0 front panel ports are implemented using three dual-
port internal headers
• Three SATA 3 Gb/s ports through the Intel H61 Express Chipset
• One serial port header
• One parallel port back panel connector
• One PS/2* back panel connector for mouse/keyboard support
LAN Support
• Intel
®
82579V Gigabit (10/100/1000 Mb/s) Ethernet LAN controller
Legacy I/O
• Nuvoton* W83677HG-i I/O controller for hardware management
and serial port, parallel port, and PS/2 support
BIOS
• Intel
®
BIOS resident in an SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI),
Plug and Play, and SMBIOS
Instantly Available
PC Technology
• Support for PCI Express Base Specification, Revision 2.0
• Suspend to RAM support
• Wake on PCI Express, LAN, front panel, serial, USB ports, and PS/2
Hardware
Monitoring
• Hardware monitoring through the Nuvoton I/O controller
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Two fan headers using PWM control
• 4-pin headers for the processor and system fans
• 4-wire and 3-wire (linear) fan speed control support for the system
fan header
• Support for Platform Environmental Control Interface (PECI)
To Next Page
