24
1.11.1 Audio Subsystem Software
Audio software and drivers are available from Intel’s World Wide Web site.
For information about Refer to
Obtaining audio software and drivers Section 1.3, page 16
1.11.2 Audio Headers and Connectors
The board contains audio connectors and headers on both the back panel and the
component side of the board. The component-side audio headers include the
following:
• Front panel audio (a 2 x 5-pin header that provides headphone and mic in signals
for front panel audio connectors) (yellow)
• S/PDIF audio header (1 x 4-pin header) (yellow)
• Internal mono speaker header (1 x 2-pin header) (yellow)
For information about Refer to
The locations of the front panel audio header, S/PDIF header, and
internal mono speaker header
Figure 10, page 42
The signal names of the front panel audio header Table 16 and Table 17, page 45
The signal names of the S/PDIF header Table 14, page 44
The signal names of the internal mono speaker header Table 15, page 44
The back panel audio connectors Section 2.2.1, page 41
