Intel Desktop Board DP55WG Specification Update
7
Specification Changes
The Specification Changes listed in this section apply to the Intel
®
Desktop Board
DP55WG Technical Product Specification (Order Number E70715).
1. Update to Section 1.5 System Memory.
1.5 System Memory
The Desktop Board supports the following memory and interface:
• Four 240-pin Double Data Rate 3 (DDR3) SDRAM Dual Inline Memory Module
(DIMM) connectors with gold-plated contacts arranged in two channels
• 1600+/1333/1066 MHz DDR3 SDRAM Memory Modules
• Support for single- and dual-channel memory interleaving
• Unbuffered, non-registered single- or double-sided DIMMs with a voltage rating of
1.65 V or less.
NOTE
Using a DIMM with a voltage rating higher than 1.65 V may damage the processor.
NOTE
DDR3 1600 or higher memory support on this desktop board requires compatible XMP
enabled memory or advanced knowledge of BIOS and manual memory tuning.
Individual results may vary.
2. Add additional information to Section 1.5 System Memory.
1.5 System Memory
The Desktop Board supports the following memory and interface:
• Four 240-pin Double Data Rate 3 (DDR3) SDRAM Dual Inline Memory Module
(DIMM) connectors with gold-plated contacts arranged in two channels
• 1600+/1333/1066 MHz DDR3 SDRAM Memory Modules
• Support for single- and dual-channel memory interleaving
• Unbuffered, non-registered single- or double-sided DIMMs with a voltage rating of
1.65 V or less
• 16 GB maximum total system memory (with 2 Gb memory technology). Refer to
Section 2.1.1 on page 39 for information on the total amount of addressable
memory.
• Minimum total system memory: 1 GB using 512 MB x16 module
• Non-ECC DIMMs
