Intel Desktop Board DP965LT Product Guide
12
Table 2. Desktop Board DP965LT Components
Label Description
A PCI bus connector 3
B Auxiliary chassis fan header (4-pin)
C PCI Express x 1 connector 3
D PCI Express x 1 connector 2
E High Definition Audio Link header
F PCI bus connector 2
G Front panel audio header
H PCI bus connector 1
I PCI Express x 1 connector 1
J PCI Express x 16 connector
K Back panel connectors
L 12 V processor core voltage connector (2 x 2 pin )
M Rear chassis fan header (3-pin)
N Processor socket
O Processor fan header (4-pin)
P Serial header
Q Main power connector (2 x 12 pin)
R Diskette drive connector
S DDR2 DIMM 0 sockets
T DDR2 DIMM 1 sockets
U Battery
V Front chassis fan header (3-pin)
W Chassis intrusion header
X BIOS configuration jumper block
Y Alternate front panel power LED header
Z Front panel header
AA Serial ATA connectors
BB IDE connector
CC High-speed USB 2.0 headers
DD Speaker
EE IEEE 1394a header
Related Links:
Go to the following links for more information about:
• Desktop Board DP965LT
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
• Supported processors
http://support.intel.com/support/motherboards/desktop
• Audio software and utilities
http://www.intel.com/design/motherbd
• LAN software and drivers
http://www.intel.com/design/motherbd
