Intel NUC 12 Pro Kit NUC12WSHi3 User Manual

10
NUC12WSH
User Guide – August 2022
4.0 Install an M.2 SSD
Intel® NUC 12 Pro Kit NUC12WSH supports 80mm and 42mm SSDs.
Find compatible M.2 SSDs at the Intel® Product Compatibility Tool:
• Intel® NUC 12 Pro Kit NUC12WSHi3
• Intel® NUC 12 Pro Kit NUC12WSHi30L
• Intel® NUC 12 Pro Kit NUC12WSHi30Z
• Intel® NUC 12 Pro Kit NUC12WSHi5
• Intel® NUC 12 Pro Kit NUC12WSHi50Z
• Intel® NUC 12 Pro Kit NUC12WSHv5
• Intel® NUC 12 Pro Kit NUC12WSHv50L
• Intel® NUC 12 Pro Kit NUC12WSHv50Z
• Intel® NUC 12 Pro Kit NUC12WSHi7
• Intel® NUC 12 Pro Kit NUC12WSHi70Z
• Intel® NUC 12 Pro Kit NUC12WSHv7
• Intel® NUC 12 Pro Kit NUC12WSHv70L
• Intel® NUC 12 Pro Kit NUC12WSHv70Z
If you’re installing an 80mm M.2 SSD:
1. Remove the small silver screw from the 80mm metal standoff on the
motherboard (A).
2. Align the small notch at the bottom edge of the M.2 card with the key in the
connector.
3. Insert the bottom edge of the M.2 card into the connector (B).
4. Secure the card to the standoff with the small silver screw (C).

Intel NUC 12 Pro Kit NUC12WSHi3 Specifications

General

Brand	Intel
Model	NUC 12 Pro Kit NUC12WSHi3
Category	Desktop
Language	English
