4.0 Install an M.2 SSD
Intel® NUC 12 Pro Kit NUC12WSH supports 80mm and 42mm SSDs.
Find compatible M.2 SSDs at the Intel® Product Compatibility Tool:
• Intel® NUC 12 Pro Kit NUC12WSKi3
• Intel® NUC 12 Pro Kit NUC12WSKi30Z
• Intel® NUC 12 Pro Kit NUC12WSKi5
• Intel® NUC 12 Pro Kit NUC12WSKi50Z
• Intel® NUC 12 Pro Kit NUC12WSKv5
• Intel® NUC 12 Pro Kit NUC12WSKv50Z
• Intel® NUC 12 Pro Kit NUC12WSKi7
• Intel® NUC 12 Pro Kit NUC12WSKi70Z
• Intel® NUC 12 Pro Kit NUC12WSKv7
• Intel® NUC 12 Pro Kit NUC12WSKv70Z
If you’re installing an 80mm M.2 SSD:
1. Remove the small silver screw from the 80mm metal standoff on the
motherboard (A).
2. Align the small notch at the bottom edge of the M.2 card with the key in the
connector.
3. Insert the bottom edge of the M.2 card into the connector (B).
4. Secure the card to the standoff with the small silver screw (C).
