17
NUC13RNGi9, NUC13RNGi7, NUC13RNGi5, NUC13SBBi9, NUC13SBBi7, NUC13SBBi5.
User Guide – July 2023
To install M.2 SSD:
1. Remove the M.2 cover.
2. Remove the pre-installed SSD from the connector if there are any.
3. Make sure there is the metal standoff in the right position, depending on the
length of the SSD you are going to install.
4. Align the space at the bottom of the new M.2 SSD to the key on the connector
and slide the SSD into the m.2 slot.
5. Secure SSD with the small screw.
6. Secure the M.2 cover.
