Intel NUC Kit DE3815TYKHE User Manual

Intel NUC Kit DE3815TYKHE User Guide
5
CAUTION
When installing a Mini-PCIe wireless adapter on the Intel NUC, ensure that the adapter is fully seated in
the connector before you power on the system. If the adapter is not fully seated in the connector, an
electrical short may result across the connector pins. Depending on the over-current protection of the
power supply, certain Intel NUC components and/or traces may be damaged.
Install a Mini-PCIe Wireless Adapter
Follow these instructions to install a Mini-PCIe wireless adapter:
1. Observe the precautions in "Before You Begin" on page 2.
2. Remove the small silver screw from the metal standoff on the mot herboard (A).
3. Align the small notch at the bottom edge of the wireless card with the key in the connector.
4. Insert the bottom edge of the wireless card into the connector (B).

Intel NUC Kit DE3815TYKHE Specifications

General

Brand	Intel
Model	NUC Kit DE3815TYKHE
Category	Desktop
Language	English
