Intellian t110W - Installation Kit

17
INSTALLING THE ANTENNA
Item Image Q’ty Description Size Remark
1
2
ACU
Bracket
Rack - ACU-19inch Rack
2 Table - ACU-Table
2 1
RG6 Cable
(Optional)
30m ACU to ANT
3
1 RG6 Cable 15m
ACU to Receiver
1 RG6 Cable 3m
4 1
AC Power Cord
(CEE7/7)
1.5m ACU Power
5 1 PC Serial Cable 1.8m ACU to PC
Installation Kit
Contains the items required for securing the antenna unit and ACU to your
vessel.
ACU Q’ty Description Size Remark
5
Self-Tapping
Screw
4 x 16
Table Mount
Bracket
10
Flat Head Screw M4 x 12L
Rack Mount
Bracket ACU
5
Sems Bolt M3 x 12L
Table Mount
Bracket ACU
Other Components
