Intellian t110W Installation And Operation User Guide

t110W/t130W/t110Q/t130Q – Marine Satellite Television System
34
Connecting the System's Cables
The t130W is capable of receiving multiband and multi-polarization satellite TV
service around the globe using the Intellian WorldView
TM
LNB module.
The t130Q is optimized for European waters using by Universal Quad LNB has
two LO(9.75GHz, 10.6GHz) and the Universal Quad LNB module. It provides higher
optimized gain for especially European water.
Multi-Switch Connection
When the receivers are connected to the antenna outputs through the multi-
switch, set the Quattro Switching Module(QSM) to Quattro mode. Be sure to set
to Quattro mode.
18V 13V 18V+22KHz 13V+22KHz
Horizontal Low Vertical Low Horizontal High Vertical High
NOTE: Intellian recommends connecting cables per the following conguration. If
you require a different conguration, contact the Intellian's service team for additional
assistance.
