Intellitec Battery Disconnect BD0 User Manual

BATTERY DISCOECT
Trouble Shooting
Problem
Possible
Cause/Solution
8
INTELLITEC
PDX RV LLC
House Relay won't
disengage, BD0 &
BD1 MODELS
ONLY
BD0 (BROWN/GOLD) 01-00066-000
Parts link:
http://www.pdxrv.com/catalog/i1399.html
BD0 (BLACK/SILVER) 01-00066-004
Parts link:
http://www.pdxrv.com/catalog/i2755.html
BD1 (BROWN/GOLD) 01-00066-001
Parts link:
http://www.pdxrv.com/catalog/i1364.html
BD1 (BLACK/SILVER) 01-00066-005
Parts link:
http://www.pdxrv.com/catalog/i2757.html
BD2 (BROWN/GOLD) 01-00066-002
Parts link:
http://www.pdxrv.com/catalog/i1363.html
BD2 (BLACK/SILVER) 01-00066-006
Parts link:
http://www.pdxrv.com/catalog/i2758.html
BD3 (BROWN/GOLD) 01-00066-003
Parts link:
http://www.pdxrv.com/catalog/i1400.html
BD3 (BLACK/SILVER) 01-00066-007
Parts link:
http://www.pdxrv.com/catalog/i2759.html
PARTS LINK #2
With a multi
-
meter set on DC voltage, measure
between the black wire at pin # 6 and the white
wire on pin # 4 while the switch is pressed. The
voltage should read the same approximate value as
the batteries. If not replace disconnect panel, refer
to PARTS LINK # 2 (this page).
STEP 7
Problem
Possible
Cause/Solution
Check fuses on relay
. If not blown go to step 10, if
blown replace with size fuse and retest. If fuse / fuses
re-blow go to step 9.
Disconnect
harness
from battery disconnect
panel inside of RV, replace fuse, if fuse re-blows
either attempt to find damage in the harness
and repair or replace harness, (see P# 1 link
page 7). If fuse doesn’t blow then go to step 10.
STEP 8
STEP 9
Check battery voltage,
the voltage
must be greater
than 10.5 Volts DC for the latching relay to close or
open. If batteries are below 10.5 Volts DC, charge
batteries and retest. If the batteries are charged and
are above 10.5 Volts DC go to step11.
ST
EP 10
House
Relay won't
engage, BD0 & BD1
MODELS ONLY
Trouble Shooting
