Intellitec Battery Guard 1000 User Manual

53‐01118‐100RevB06/09/2020
Page2
USER’SGUIDE




Diagnostics

IftheBatteryGuard®1000isfailstooperateasintended,locatethedevice.TheBatteryGuard®1000providesa
diagnosticLEDonthemodulethatindicatesseveralfailuremodes.


(DiagnosticLEDlocatedinthelowerrightcorner)

1Blink–Failedtodisconnect
2Blinks–Failedtoreconnect
3Blinks–Belowminimumdisconnectvoltage.

ThisinformationcanbeveryusefulwhentryingtotroubleshoottheBatteryGuard®1000.Intheeventthat
thereisanissueandtheoperatorneedstobypassthedisconnect.RemovetheSystemloadwirefromthe
BatteryGuard1000terminalandmoveittothesamesideasthepositivebatteryfeed.

WARNING:Beforeperformingthistask,disconnectallsourcesofpower.Unplugthecoachandturnoffthe
generator.Disconnectthebattery(s)negative(‐)terminal.
OperatingParameters

ThetablebelowdefinestheoperatingparametersusedbytheBatteryGuard®1000.Thedevicecomeswithtwo
setsofpreconfiguredparameters,oneforchassisdisconnectsandoneforcoachdisconnects.Dependingon
whatmodethedeviceisin,theparametersmayvary.

Parameter ChassisBattery CoachBattery
LowVoltageDisconnectThreshold 12.1Volts 10.5Volts
IsolationDelay 5Minutes 3Minutes
MinimumDisconnectThreshold 9.0Volts
ChargingVoltageThreshold 13.3Volts
ReconnectDelay 1Minute
StateChangeDelay 5Seconds


Refertothe53‐01118‐200InstallationGuideonhowtoswitchbetweenconfigurations.


Intellitec Battery Guard 1000 Specifications

General

Brand	Intellitec
Model	Battery Guard 1000
Category	Control Unit
Language	English
