EMERGENCY PANEL
4
EP-6216
Front Panel
Front Panel
1. FIRE INDICATOR
This panel blinks red when fire has been detected.
2. OUTPUT INDICATOR LED
Audio signal level indication.
3. MICROPHONE AND BUILT-IN SPEAKER
The unit contains a built-in uni-directional dynamic microphone, and a built-in speaker for convenient local
monitoring.
4. TEST SWITCH
This switch is used to check system. When the switch is pressed, the relevant LED lights.
5. STANDBY INDICATOR LED
This LED will light to indicate that power has been applied to the unit, and the unit is in Standby mode.
6. MIC VOLUME
This knob controls the mic output volume. Rotating in a clockwise direction increases volume.
