Inter-m PA-120 User Manual

∴
SPECIFICATION
P
A-120
Rated Output 120W
Frequency Response (@ Speaker Output, 1W) 80Hz - 15kHz
THD (@ Rated Power, 1kHz)
less than 1%
S/N (@ Rated Output, Line Input) more than 78dB
TONE CONTROL (100Hz, 10kHz, ±3dB) ±10dB
Input Sensitivity / Impedance (@ High-Z Output)
INPUT 1~5
MIC
-50dBu / 2kΩ
LINE
-10dBu / 2kΩ
INPUT 6
-10dBu / 10kΩ
TEL IN
0dBu / 10kΩ
EXT IN
0dBu / 20kΩ
MIX OUT / Impedance
0dBu / 10kΩ
Speaker Output Level/
Impedance
Low-Z
Output Level
120W / 8Ω
Impedance
8Ω, 4Ω
High-Z
Output Level 100V
Impedance
84Ω
Output Level 70V
Impedance
41Ω
Operating Temperature -10℃ ~ +40℃
Power Source
AC 120V/60Hz or AC 230V/50Hz or AC 240V/50Hz
(Supplied AC mains transformer depends on contrary requirements)
Power Consumption 60W
Weight 7.4kg/ 16.3Ib
Dimensions (W x H x D) 420 x 88 x 319mm/16.5 x 3.5 x 12.6in

Inter-m PA-120 Specifications

General

Brand	Inter-m
Model	PA-120
Category	Amplifier
Language	English
