ELECTRICAL PARTS LIST
Ref No. Part No. Description Value
AMP B'D (4005196001)
R50 R57(PA-9312) 3009681973 RES CF 680 1/5W J N 680
R50 R57(PA-9324) 3009102973 RES CF 1K 1/5W J N 1K
R43(PA-9312) 3009561973 RES CF 560 1/5W J N 560
R43(PA-9324) 3009391973 RES CF 390 1/5W J N 390
D71(PA-9312) 2058300998 DIODE SCHOTTKY SBL2040/SR2040 SBL 2040
D71(PA-9324) 2058300997 DIODE SCHOTTKY SBL-3040PT SBL 3040
TP1 TP2 TP3 TP5 4225000810-T TEST POINT(NZ0352-001Z) TEST POINT
Q1 Q19-20 Q72-73 Q75 2008606104-T TR NPN KTC3198-Y-AT TO-92 KTC 3198Y
Q74 2008606105-T TR NPN KTA1266-Y-AT TO-92 KTA1266Y
Q5 Q7 2008606107-T KTC3206-Y-AT KTC 2229Y
Q77 2008606108-T KTC3200-BL-AT C2240
Q71 Q76 2028406113 KTD2058-Y-U KTD 2058Y
Q9 Q13-14 Q16 Q18 Q11 2028427998 TR 2SC 3856 W/ACC 2SC 3856
2028427998 TR 2SC 3856 W/ACC 2SC 3856
Q4 Q6 Q8 2028407118 KTC2238A-Y-U 2SC 2238Y
D1-4,74,77-78,80-82 2058304100 DIODE IN4148M 1N4148
D81 2058500973 DIODE UZ-4.7BM UZ 4.7BM
D73 2058502082 DIODE ZENER UZ-8.2BM(1N5237B) UZ 8.2BM
D75-76 2058502120 DIODE ZENER UZ-12BM(1N5242B) UZ 12BM
D72 2058502180 DIODE ZENER UZ-18BM(1N5248B) UZ 18BM
D79 2058502200 DIODE ZENER UZ-20BM(1N5250B) UZ 20BM
IC02A 2118010590 IC NJM4558D JRC NJM 4558D
TH1 TH71 2438209031 THERMISTOR YSG-503J L=100 50K
T1 2808098300 TRANSFORMER INPUT (PA-9324) IPT
R93 3002536953 RES CF 53.6K 1/5W F N 53.6K 1%
R87 3002715953 RES CF 71.5K 1/5W FN 71.5K 1%
R89 3003130953 RES CF 1.3K 1/5W F N 1.3K 1%
R86 3003332953 RES CF 3.32K 1/5W F N 3.32K 1%
R90 3003634953 RES CF 6.34K 1/5W F N 6.34K 1%
R85 3009101973 RES CF 100 1/5W J N 100
R75 R91 3009102973 RES CF 1K 1/5W J N 1K
R81 R88 3009103973 RES CF 10K 1/5W J N 10K
R80 R92 3009104973 RES CF 100K 1/5W J N 100K
R78 3009105973 RES CF 1M 1/5W J N 1M
R48 R54 3009151973 RES CF 150 1/5W J N 150
R35 3009151973 RES CF 150 1/5W J N 150K
R19 3009202973 RES CF 2K 1/5W J N 2K
1 / 5
