Ref No. Part No. Description Value Ref No. Part No. Description Value
R105-106 3009752973 RES MF 7.5K 1/5W 5% AX N TA 7.5K
R137 R182 3009821973 RES MF 820 1/5W 5% AX N TA 820
TP1-2 4678699410 CNT PLUG 1P CNT1P R200 3039100572-F RES MF 10 2W 5% AX P 10 2W
Q110 Q117 2008206997-T TR SG PNP KTA1024 TO A1024Y R209-210 3039221572-F RES MF 220 2W 5% AX P 220 2W
Q113 2008206998-T TR SG PNP KTA1023 T KTA1023Y VR104-105 3228089410 VR ROT HOR 1U BUSH L20 100K W 100KW
Q111 2008407970-T TR SG NPN KTC1027 T C1027Y VR101-103 3228089510 VR ROT HOR 1U BUSH L20 10K A 10KA
Q101-103 2008606104-T TR SG NPN KTC3198 TO C3198Y SVR102-103 3228090110-S VR SEMI CE TOP 5MM 10K 10K
Q105-106 SVR104 3248520120-T RES SEMI FT-63 TP(200) 200
Q104 Q107 2008606998-T TR SG NPN KTD1302 TO D1302 SVR101 3248550220-T RES SEMI FT-63 TP(5K) 5K
Q115-116 C172-173 3408222261 CAP E SM SG 85C 2200UF 35V M 1 2200/35
Q108-109 2008606999-T TR SG NPN KTC3198 TO C3198BL C103-104 C106 3409210071-T CAP E SM SG 85C 10UF 50V M 5P 10/50
Q112 Q114 2028443879 TR PW NPN 2SC5197TO-3 C5197 C118-119 C122
BD 2058100995 DIODE BR PBPC-306 SB-3 PBPC306 C125-126 C128
D104 2058100996 DIODE RE 1N4006 DO-41 1N 4006 C131 C161
D101-102 2058304100 DIODE SW 1N4148M DO- 1N4148 C159 3409210071-T CAP E SM SG 85C 10UF 50V M 5P 10/50
D105-112 C107 C110-111 3409210141-T CAP E SM SG 85C 100UF 25V M 6P 100/25
D103 2058502180 DIODE ZN 500MW BM 18V DO-35 18BM C121 C129 C138
U101-102 2118010432 IC OP AMP NJM2068D DIP8 2068DD C142 C147 C153
U103-104 2118010590 IC OP AMP NJM4558D DIP8 4558D C156-157
U106 2128610800 IC VOLT REG -15V 1A 7915 TO-22 7915 C164-166
U105 2128610900 IC VOLT REG 15V 1A 7815 TO-220 7815 C160 C167 3409210171-T CAP E SM SG 85C 100UF 50V M 8P 100/50
R189 R191 3009100973 RES MF 10 1/5W 5% AX N 10 C170-171
R107 R112-113 3009101973 RES MF 100 1/5W 5% AX N 100 C108 C114 C137 3409210971-T CAP E SM SG 85C 1UF 50V M 5P T 1/50
R123 R132 R151 C144 C146 3409222971-T CAP E SM SG 85C 2.2UF 50V M 5P 2.2/50
R174 R176 R186 C143 3409233071-T CAP E SM SG 85C 33UF 50V M 6P 33/50
R188 R201 C158 3409233871-T CAP E SM SG 85C 0.33UF 50V M 6 0.33/50
R153 R178 3009102973 RES MF 1K 1/5W 5% AX N 1K C115 C130 3409247871-T CAP E SM SG 85C 0.47UF 50V M 5 0.47/50
R101-102 R108 3009103973 RES MF 10K 1/5W 5% AX N 10K C134-135
R115 R117-118 C112 C154 3409247971-T CAP E SM SG 85C 4.7UF 50V M 5P 4.7/50
R126-127 C113 C155 3509101130-T CAP CE TEMP SL 100PF 50V J RA 100P
R145-146 R152 C101-102 3509102530-T CAP CE HI-DI Y5P 1000PF 50V J 0.001
R172 R175 R177 C116-117
R124 R133 3009104973 RES MF 100K 1/5W 5% AX N 100K C123-124 C136
R147-148 3009122973 RES MF 1.2K 1/5W 5% AX N 1.2K C174
R109 R125 R134 3009123973 RES MF 12K 1/5W 5% AX N 12K C105 3509121130-T CAP CE TEMP SL 120PF 50V J RA 120P
R154 R202 C120 C127 3509150130-T CAP CE TEMP SL 15PF 50V J RA T 15P
R111 3009124973 RES MF 120K 1/5W 5% AX N 120K C162 3509330130-T CAP CE TEMP SL 33PF 50V J RA T 33P
R144 3009132973 RES MF 1.3K 1/5W 5% AX N 1.3K C109 C151 3509470130-T CAP CE TEMP SL 47PF 50V J RA T 47P
R187 3009150973 RES MF 15 1/5W 5% AX N 15 C132-133 3509472530-T CAP CE HI-DI Y5V 4700PF 50V Z 0.0047
R168 R171 3009153973 RES MF 15K 1/5W 5% AX N 15K SP_CAP 3549472407 CAP CE AC Y2/X1 4700PF 250VAC 4700P
R135-136 3009182973 RES MF 1.8K 1/5W 5% AX N 1.8K C140 3609103120-T CAP FILM POLYESTR 0.01UF 100V 0.01(M)
R138-139 3009203973 RES MF 20K 1/5W 5% AX N 20K C168-169 3609104120-T CAP FILM POLYESTR 0.1UF 100V J 0.1(M)
R165 3009221973 RES MF 220 1/5W 5% AX N 220 C152 3609122120-T CAP FILM POLYESTR 0.0012UF 100 0.0012(M)
R179 R183 R208 3009223973 RES CF 22K 1/5W J N 22K C148 C150 3609123120-T CAP FILM POLYESTR 0.012UF 100V 0.012(M)
R142 3009224973 RES CF 220K 1/5W J N 220K C145 3609182120-T CAP FILM POLYESTR 0.0018UF 100 0.0018(M)
R141 R157 R163 3009225973 RES MF 2.2M 1/5W 5% AX N 2.2M C163 3609563120-T CAP FILM POLYESTR 0.056UF 100V 0.056(M)
R181 R199 3009272973 RES MF 2.7K 1/5W 5% AX N 2.7K C139 C141 3609683120-T CAP FILM POLYESTR 0.068UF 100V 0.068(M)
R166 3009274973 RES MF 270K 1/5W 5% AX N 270K AN102 4355709101 CON ASS'Y 2P 80MM ASS'Y 2P_80
R170 R173 3009303973 RES MF 30K 1/5W 5% AX N 30K AN201 4355709203 CON ASS'Y 3P 100MM ASS'Y 3P_100
R204 3009330973 RES MF 33 1/5W 5% AX N 33 AN101 4355709309 CON ASS'Y 3P 190MM ASS'Y 3P_190
R116 3009331973 RES MF 330 1/5W 5% AX N 330 CN1 CN9 4428596603 CON WAFER LOCK(M) 3P ST LW1143-03
R114 3009332973 RES MF 3.3K 1/5W 5% AX N 3.3K SW101-102 4618001110 SW SLIDE HOR DPDT NS L7.5 SLIDE SW
R159 3009334973 RES MF 330K 1/5W 5% AX N 330K SW 4648098510 SW PUSH HOR SPST NS 1U BKT L18 POWER SW
R143 R207 3009392973 RES MF 3.9K 1/5W 5% AX N 3.9K R190 R192 C3059228776 RES CE 0.27 Ω 5W RA T 0.27 5W
R158 R164 R180 3009393973 RES MF 39K 1/5W 5% AX N 39K JK1-4 C4438097210 JACK PHONE 1U 4P AN JY-6313
R203 3009394973 RES MF 390K 1/5W 5% AX N 390K JK5 C4438189120 JACK RCA 1U 2P AN RJ-1060
R140 3009431973 RES MF 430 1/5W 5% AX N 430
R206 3009471973 RES MF 470 1/5W 5% AX N 470
R149-150 R155 3009472973 RES MF 4.7K 1/5W 5% AX N 4.7K
R184-185
R156 3009473973 RES MF 47K 1/5W 5% AX N 47K
R103-104 3009561973 RES MF 560 1/5W 5% AX N 560
R119-120
R128-129 R161
R110 R160 R205 3009562973 RES MF 5.6K 1/5W 5% AX N 5.6K
R162 R167 R169 3009563973 RES MF 56K 1/5W 5% AX N 56K
R121-122 3009682973 RES MF 6.8K 1/5W 5% AX N 6.8K
R130-131
MAIN B'D (C4005407500)
ELECTRICAL PARTLIST
