6
PA-935A
AMPLIFIER
6. AC CORD
Connect this cable to your AC outlet.
7. TELEPHONE IN TERMINAL
These terminals are used to connect to a telephone exchange system for paging purposes.
NOTE: When signal is present on the Telephone Input terminal, all other input signals (except Mic 1) are
muted.
8. MUTE CONTROLS
When signal is present at Mic 1 or Telephone input, all other inputs are muted. These controls adjust the level
of Mic 1 and Telephone output when muting is in use.
9. AUX INPUT
This input is used for connecting line-level sources, such as CD or cassette deck. When using this input, the
respective Mic/AUX switch must be set to its AUX setting.
10. MIC 2/AUX SELECTOR SWITCH
This switch is used to select between mic level and line level for Mic 2/AUX input.
