Inter-m PMU-60N - Specifications

MIXING AMPLIFIER
28
PMU-60N/120N/240N
PMU-60N PMU-120N PMU-240N
Rated Output Power 60W 120W 240W
Frequency Response (SP OUT/1W output) 80Hz~15kHz
T.H.D (Rated Output, 1kHz) Less than 0.5%
S/N (Rated Output) More than 78dB
Tone Control (100Hz, 10kHz) ±10dB
Input Sensitivity/ Input 1~5 MIC -50dBu/2kΩ
Impedance
LINE -10dBu/2kΩ
Input 6 -10dBu/10kΩ
TEL IN 0dBu/10kΩ
EXT IN 0dBu/20kΩ
MIX Out/Impedance 0dBu/10kΩ
Speaker Output Level/Impedance LOW-Z 15.5V/4Ω 22V/4Ω 31V/4Ω
HIGH-Z
100V/167Ω 100V/83Ω 100V/42Ω
70V/83Ω 70V/42Ω 70V/21Ω
Operation Temperature -10°C ~ +40°C
Power Source 100-120VAC or 220-240VAC; 50/60Hz
(Supplied AC mains transformer depends on country requirements)
Power Consumption (1/8W output) 50W 75W
Weight (SET) 5.4kg/11.9lb 6.7kg/14.8lb 8.0kg/17.6lb
Dimensions (SET) 420(W)x88(H)x319(D)mm/16.5(W)x3.5(H)x12.6(D)in
* Design and specification are subject to be changed for the improvement of product quality without pre notice.
