Inter-m POP-30 Service Manual

R39 3009224973 RES CF 220K 1/5W J N 220K 1
R29 3009274973 RES CF 270K 1/5W J N 270K 1
R26 3009273973 RES CF 27K 1/5W J N 27K 1
R37 3009202973 RES CF 2K 1/5W J N 2K 1
R44 3009333973 RES CF 33K 1/5W J N 33K 1
R43 3009393973 RES CF 39K 1/5W J N 39K 1
R53 3039479575-T RES MO 4.7 2W J RADIAL 4.7 2W 1
R25 3009472973 RES CF 4.7K 1/5W J N 4.7K 1
R54-55 R54-1 R55-1 3039470575-T RES MO 47 2W J RADIAL 47 2W 4
R41 R46 3009473973 RES CF 47K 1/5W J N 47K 2
R49 3039561575-T RES MO 560 2W J RADIAL 560 2W 1
R48 3009564973 RES CF 560K 1/5W J N 560K 1
R50-51 R50-1 R51-1 3039560575-T RES MO 56 2W J RADIAL 56 2W 4
R45 3009563973 RES CF 56K 1/5W J N 56K 1
R5 3009683973 RES CF 68K 1/5W J N 68K 1
R32 3009822973 RES CF 8.2K 1/5W J N 8.2K 1
R3-4 3009821973 RES CF 820 1/5W J N 820 2
SVR1 3238082110 VR RV09A-20-25K-A14 ALPHA 10KA 1
T2-4 4225000810-T TEST POINT (NZ0352-001Z) TEST POINT 3
XLR1-2
4438193710
XLR JACK(F) 3P(E303A0070N)
XLR JACK
2
C68 3509102530-T CAP CE B 0.001UF 50V J 0.001/50 1
C67 3509101130-T CAP CE SL 100PF 50V J 100P 1
C66 3509470130-T CAP CE SL 47PF 50V J 47P 1
C69-70 3509561130-T CAP CE B 560PF 50V J 560P 2
C78 3409247871-T CAP AF RSG 0.47UF 50V 5 P 0.47/50 1
C71 3409210971-T CAP AF RSG 1UF 50V 5 P 1/50 1
C73 C75-76 C79-80 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50 5
C61-62(POP-30) 3408222271 CAP RSA 2200UF 50V SNAP 18 P 2200/50 2
C61-62(POP-60) 3419533279 CAP LSW332M 1HO25M(3300UF/50V) 3300/50 2
C61-62(POP-120) 3409247280 CAP LSW472M1JP30M(4700UF/63V) 4700/63 2
C81 3409247041-T CAP AF RSG 47UF 25V 5 P 47/25 1
C72 C74 3409247071-T CAP AF RSG 47UF 50V 6 P 47/50 2
C65 3609272120-T CAP MA 0.0027UF 100V J 0.0027/100(M) 1
C63-64 3609104140 CAP MA 0.1UF 200V J 0.1/200(M) 2
CON9 4428596602 WAFER LW-1143-02P LW-1143-2P 1
CON11-12 4428595002 LW5267/LWB0640/2.5MM-02P LW-5267-2P 2
CON10 4428596603 LOCK WAFER LW-1143-03P LW-1143-3P 1
D9 2058100988 DIODE BRIDGE PBU 804 PBU 804 1
D16-17 2058010101 DIODE IN 60 1N 60 2
D14-15 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006 2
D10-13 2058304100 DIODE IN4148M 1N 4148 4
IC8 2118050410 IC TA7317P TOSHIBA TA 7317P 1
IDLE1-3 4678699411 CNT PLUG 1P CNT 1P 3
IDEL 3248347120 RES RH0615C100471 (470B) 470B 1
OFFSET 3248310220 RES SEMI RH0615C100102 1KB 1
Q18-19 2008407970-T KTC1027-Y-AT KTC1027 2
Q10 2028407118 KTC2238A-Y-U 2SC 2238Y 1
Q7(POP-30) 2028407109 TR NPN 2SC5197 TOSHIBA 2SD 718 1
Q6-7(POP-60) 2028407109 TR NPN 2SC5197 TOSHIBA 2SD 718 2
Q6-7(POP-120) 2028427998 TR 2SC 3856 W/ACC 2SC 3856 2
Q8-9(POP-120) 2028107108 TR PNP 2SB1429.0 2SB 1429 2
Q8-9(POP-60) 2028107106 TR PNP 2SB688(O)/2SA1940 2SB 688 2
Q8(POP-30) 2028107106 TR PNP 2SB688(O)/2SA1940 2SB 688 1
Q12-15 Q20 2008606108-T KTC3200-BL-AT KTC 3200BL 5
Q21 2008606104-T TR NPN KTC3198-Y-AT TO-92 KTC 3198Y 1
Q22 2008606105-T TR NPN KTA1266-Y-AT TO-92 2SA 1266GR 1
Q16-17 2008206998-T KTA1023-Y-AT KTA1023 2
Q11 2028107115 KTA968A-Y-U 2SA 968Y 1
R56 R58(POP-30) 3059478783 RES CE 0.47 5W J T 0.47 5W 2
R56-59(POP-60) 3059478783 RES CE 0.47 5W J T 0.47 5W 4
R56-59(POP-120) 3059278783 RES CE 0.27 5W J T 0.27 5W 4
R65 R68 R86-87 3009152973 RES CF 1.5K 1/5W J N 1.5K 4
POWER B'D (4005413000)
