Inter-m POP-30 Service Manual

R63(POP-30) 3039151575-T RES MO 150 2W J RADIAL 150 2W 1
R63(POP-60) 3039681575-T RES MO 680 2W J RASIAL 680 2W 1
R63(POP-120) 3039821575-T RES MO 820 2W J RADIAL 820 2W 1
R77 3009101973 RES CF 100 1/5W J N 100 1
R93 3009104973 RES CF 100K 1/5W J N 100K 1
R69 R74-76 3009103973 RES CF 10K 1/5W J N 10K 4
R62 3039103575-T RES MO 10K 2W JR 10K 2W 1
R88 R92 R96 R98 3009153973 RES CF 15K 1/5W J N 15K 4
R71-72 R81 3009102973 RES CF 1K 1/5W J N 1K 3
R83 3009222973 RES CF 2.2K 1/5W J N 2.2K 1
R66 R84-85 3009203973 RES CF 20K 1/5W J N 20K 3
R60-61 3039203473-T RES MO 20K 1W J T 20K 1W 2
R78-79 3009221973 RES CF 220 1/5W J N 220 2
R97 3009224973 RES CF 220K 1/5W J N 220K 1
R64 3039271575-T RES MO 270 2W J RADIAL 270 1
R99 3009333973 RES CF 33K 1/5W J N 33K 1
R90 3009302973 RES CF 3K 1/5W J N 3K 1
R73 3009471973 RES CF 470 1/5W J N 470 1
R70 R95 3009473973 RES CF 47K 1/5W J N 47K 2
R80 3009562973 RES CF 5.6K 1/5W J N 5.6K 1
R89 R91 R94 R100 3009563973 RES CF 56K 1/5W J N 56K 4
R82 3009682973 RES CF 6.8K 1/5W J N 6.8K 1
R67 3009911973 RES CF 910 1/5W J N 910 1
RLY1 5528008200 RELAY DH24D1-0 24V (DAIICHI) HR-311 1
TH1-2 2438209011 THERMISTOR YSG-503J L=100MM 50K 2
C86 3509100130-T CAP CE SL 10PF 50V D 10P 1
C89 3509151130-T CAP CE SL 150PF 50V J 150P 1
C93-94 3509509030-T CAP CE SL 5PF 50V J 5P 2
C96 C98 3409215971-T CAP AF RSG 1.5 UF 50V 5 P 1.5/50 2
C95 3409222071-T CAP AF RSG 22UF 50V 5 P 22/50 1
C88 C90 C92 C97 3409233071-T CAP AF RSG 33UF 50V 6 P 33/50 4
C87 C91 C99-100 3409247041-T CAP AF RSG 47UF 25V 5 P 47/25 4
C82 3609102120-T CAP MA 0.001UF 100V 0.001(M) 1
C85 3609152120-T CAP MA 0.0015UF 100V J 0.0015/100(M) 1
C83-84 3609103120-T CAP MA 0.01UF 100V 0.01/100(M) 2
CON11 4428595002 LW5267/LWB0640/2.5MM-02P LW-5267-2P 1
CON14 4355886418 CON ASS'Y 2P ASS'Y 2P 1
CON15 4355886221 CON ASS'Y 2P ASS'Y 2P 1
CON21 4355887221 CON ASS'Y 4P ASS'Y 4P 1
CON22 4355886112 CON ASS'Y 1P ASS'Y 1P 1
CON23-24 4355886514 CON ASS'Y 2P ASS'Y 2P 2
CON13 4355887517 CON ASS'Y 8P ASS'Y 8P 1
CON20 4355887417 CON ASS'Y 9P ASS'Y 9P 1
D18 2058304100 DIODE IN4148M 1N 4148 1
IC9-10 2118010590 IC NJM4558D JRC NJM 4558D 2
R107 3009122973 RES CF 1.2K 1/5W J N 1.2K 1
R106 R109 R111 R115 3009101973 RES CF 100 1/5W J N 100 4
R110 3009103973 RES CF 10K 1/5W J N 10K 1
R112 3009121973 RES CF 120 1/5W J N 120 1
R119-125 3009123973 RES CF 12K 1/5W J N 12K 7
R103-104 3009133973 RES CF 13K 1/5W J N 13K 2
R105 3009183973 RES CF 18K 1/5W J N 18K 1
R108 3009102973 RES CF 1K 1/5W J N 1K 1
R116 3009272973 RES CF 2.7K 1/5W J N 2.7K 1
R101-102 3009392973 RES CF 3.9K 1/5W J N 3.9K 2
R114 R118 R156 3009471973 RES CF 470 1/5W J N 470 3
R113 3009473973 RES CF 47K 1/5W J N 47K 1
SW1 4628987810 SW PUSH SPEC122RC011 (SUK78) SW 1
VR1-6 3228081010 VR RK11K114030713A (RO992) 10KA 6
VR7-8 3238082710 VR RV09A-40-30F-B54-0C ALPHA 50KB 2
C131 3409210971-T CAP AF RSG 1UF 50V 5 P 1/50 1
VR B'D (4005412810)
OUTPUT LED B'D (4005412920)
