Inter-m PW-9242N User Manual

7
D12 S22401205005 KDS160-RTK KDS160
D11 S22401205005 KDS160-RTK KDS160
D10 S22401205005 KDS160-RTK KDS160
D9 S22401205005 KDS160-RTK KDS160
D8 S22401205005 KDS160-RTK KDS160
D7 S22401205005 KDS160-RTK KDS160
D6 S22401205005 KDS160-RTK KDS160
D5 S22401205005 KDS160-RTK KDS160
D4 S22401205005 KDS160-RTK KDS160
D3 S22401205005 KDS160-RTK KDS160
D2 S22401205005 KDS160-RTK KDS160
D1 S22401205005 KDS160-RTK KDS160
AN6 4355820500 CON ASS'Y 7P (PW-9242V) CON 7P
PCB 4005179350 PCB KEY B'D PW-9242N PCB
VR1 3228084610 VR RK12K11201A2 52A (RND67) 5KB
AN3 4355724503 CON ASS'Y 3P 100MM R/2W CON 3P
PCB 4005179360 PCB VR B'D PW-9242N PCB
SW13 4628992410 SW PUSH SPUN19X1M011 (SUA29) SW
SW14 4625998010 SPUN12X1T011 SW
AN2 4355724406 CON ASS'Y 4P 130MM R/3W CON4
AN1 4355724307 CON ASS'Y 5P 150MM R/4W CON5
PCB 4005179330 PCB SW B'D PW-9242N PCB
Ref No. Part No. ValueDescription
JK9 4438193810 XLR JACK(F) 3P(E203A0040N) XRLF
JK8 4408194310 XLR JACK (M) E503A0150N XRLM
JK7 4438193810 XLR JACK(F) 3P(E203A0040N) XRLF
JK6 4408194310 XLR JACK (M) E503A0150N XRLM
JK5 4438193810 XLR JACK(F) 3P(E203A0040N) XRLF
JK4 4408194310 XLR JACK (M) E503A0150N XRLM
JK3 4438193810 XLR JACK(F) 3P(E203A0040N) XRLF
JK2 4408194310 XLR JACK (M) E503A0150N XRLM
JK1 4438193810 XLR JACK(F) 3P(E203A0040N) XRLF
D27 S22401205005 KDS160-RTK KDS160
D26 S22401205005 KDS160-RTK KDS160
D25 S22401205005 KDS160-RTK KDS160
D24 S22401205005 KDS160-RTK KDS160
D23 S22401205005 KDS160-RTK KDS160
C50 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
C49 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
C48 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
C47 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
C46 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
C45 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
C44 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
C43 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
C42 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
C41 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
AN7 4355724006 CON ASS'Y 11P 130MM R/10W CON11P
PCB 4005179310 PCB JACK B'D PW-9242N PCB
JK11 4438191010 D-SUB PLUG(M) 9P D-SUB9
JK12 4465997702 SCREW TERMINAL 2P 2P
CR11 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
CR12 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
AN8 4355724307 CON ASS'Y 5P 150MM R/4W CON 5P
PCB 4005179340 PCB COM B'D PW-9242N PCB
SEG4 2318000189 SEGMENT SC36-11EWB 1DIGIT SEGMENT(SMALL)
SEG3 2318000189 SEGMENT SC36-11EWB 1DIGIT SEGMENT(SMALL)
SEG2 2318000188 SEGMENT DC04-11EWB 2DIGIT
SEGMENT(LARGE)
SEG1 2318000188 SEGMENT DC04-11EWB 2DIGIT SEGMENT(LARGE)
LD19 2300030100 LED LTL-1CHE LITEON RED(LTL-CHE)
LD18 2300030100 LED LTL-1CHE LITEON RED(LTL-CHE)
LD17 2300030100 LED LTL-1CHE LITEON RED(LTL-CHE)
LD16 2300030100 LED LTL-1CHE LITEON RED(LTL-CHE)
LD15 2300032100 LED LTL-1CHG LITEON g(LTL-CHE)
LD14 2300032100 LED LTL-1CHG LITEON g(LTL-CHE)
LD13 2300032100 LED LTL-1CHG LITEON g(LTL-CHE)
LD12 2300032100 LED LTL-1CHG LITEON g(LTL-CHE)
LD11 2300032100 LED LTL-1CHG LITEON g(LTL-CHE)
LD10 2300032100 LED LTL-1CHG LITEON g(LTL-CHE)
LD9 2300032100 LED LTL-1CHG LITEON g(LTL-CHE)
LD8 2300032100 LED LTL-1CHG LITEON g(LTL-CHE)
LD7 2300030100 LED LTL-1CHE LITEON RED(LTL-CHE)
LD6 2300030100 LED LTL-1CHE LITEON RED(LTL-CHE)
LD5 2300030100 LED LTL-1CHE LITEON RED(LTL-CHE)
LD4 2300030100 LED LTL-1CHE LITEON RED(LTL-CHE)
LD3 2300030100 LED LTL-1CHE LITEON RED(LTL-CHE)
LD2 2300030100 LED LTL-1CHE LITEON RED(LTL-CHE)
LD1 2300030100 LED LTL-1CHE LITEON RED(LTL-CHE)
AN5 4355724108 CON ASS'Y 9P 180MM R/8W CON9
AN4 4355724208 CON ASS'Y 8P 180MM R/7W CON 8P
PCB 4005179320 PCB DISPLAY B'D PW-9242N PCB
SW12 4628985710 TACT (5MM) THVV501BAA (KBW89) SW/TACT
SW11 4628985710 TACT (5MM) THVV501BAA (KBW89) SW/TACT
SW10 4628985710 TACT (5MM) THVV501BAA (KBW89) SW/TACT
SW9 4628985710 TACT (5MM) THVV501BAA (KBW89) SW/TACT
SW8 4628985710 TACT (5MM) THVV501BAA (KBW89) SW/TACT
SW7 4628985710 TACT (5MM) THVV501BAA (KBW89) SW/TACT
SW6 4628985710 TACT (5MM) THVV501BAA (KBW89) SW/TACT
SW5 4628985710 TACT (5MM) THVV501BAA (KBW89) SW/TACT
SW4 4628985710 TACT (5MM) THVV501BAA (KBW89) SW/TACT
SW3 4628985710 TACT (5MM) THVV501BAA (KBW89) SW/TACT
SW2 4628985710 TACT (5MM) THVV501BAA (KBW89) SW/TACT
SW1 4628985710 TACT (5MM) THVV501BAA (KBW89) SW/TACT
Ref No. Part No. ValueDescription
VR B’D (4005179360)
SW B’D (4005179330)
COM B’D (4005179340)
DISPLAY B’D (4005179320)
KEY B’D (4005179350)
