Inter-m PW-9242N User Manual

D16 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006
D15 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006
D14 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006
D13 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006
CN14 4465998210 TERMINAL(250)PCB TAB 250TAB
CN13 4465998210 TERMINAL(250)PCB TAB 250TAB
CN12 4465998210 TERMINAL(250)PCB TAB 250TAB
CN11 4465998210 TERMINAL(250)PCB TAB 250TAB
CN10 4465998210 TERMINAL(250)PCB TAB 250TAB
CN8 4428595005 LW5267/LWB0640/2.5MM-05P WAFER/5P
CN7 4428595011 LW5267/LWB0640/2.5MM-11P WAFER/11P
CN6 4428595007 LW5267/LWB0640/2.5MM-07P WAFER/7P
CN5 4428595009 LW5267/LWB0640/2.5MM-09P WAFER/9P
CN4 4428595008 LW5267/LWB0640/2.5MM-08P WAFER/8P
CN3 4428595003 LW5267/LWB0640/2.5MM-03P WAFER/3P
CN2 4428595004 LW5267/LWB0640/2.5MM-04P WAFER/4P
CN1 4428595005 LW5267/LWB0640/2.5MM-05P WAFER/5P
C40 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
C39 S35101035331 CAP CE B0.01UF 50V K 0805(2012) 0.01/50
C38 3549472092 CAP DE7100F472MVAI-KC 472
C37 3549472092 CAP DE7100F472MVAI-KC 472
C36 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C35 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C34 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C33 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C32 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C31 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C30 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C29 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C28 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C27 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C26 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C25 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C24 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C23 S35101045331 CAP CE B 0.1UF 50V Z 0805(2012) 0.1/50
C22 3408247171 CAP RSA 470UF 50V SNAP 13 P 470/50
C21 3408247171 CAP RSA 470UF 50V SNAP 13 P 470/50
C20 3419522275 CAP AF HC 2200UF 50V 22P LUG 2200/50V
C19 3639104180 CAP MA 0.1UF 50V J NT-136 MA0.1/50
C18 S35101015331 CAP CE B100PF 50V K 0805(2012) 100P
C17 3409210149-T CAP RG 100UF 25V 105C 100/25
C16 S35102204339 CAP CL 22PF 50V J 2012 22P
C15 S35101015331 CAP CE B100PF 50V K 0805(2012) 100P
C14 3409210149-T CAP RG 100UF 25V 105C 100/25
C13 S35103304331 CAP CE 33PF 50V J 2012 33P
C12 3409247974-T CAP RG 4.7UF 50V 105C 4.7/50
C11 3409210071-T CAP AF RSG 10UF 50V 5 P Oct.50
C10 3409210071-T CAP AF RSG 10UF 50V 5 P Oct.50
C9 3409210871-T CAP AF RSG 0.1UF 50V 5 P 0.1/50
C8 3409233121-T CAP AF RSG 330UF 10V SG 8 P 330/10
C7 3409010971 CAP EC RSG 1F 5.5V MGC 1F
C6 S35100604321 CAP CL 6PF 50V J 1608 6P
C5 S35100604321 CAP CL 6PF 50V J 1608 6P
C4 3409210071-T CAP AF RSG 10UF 50V 5 P Oct.50
C3 3409210071-T CAP AF RSG 10UF 50V 5 P Oct.50
C2 3409210071-T CAP AF RSG 10UF 50V 5 P Oct.50
C1 3409210071-T CAP AF RSG 10UF 50V 5 P Oct.50
AR1 3096103991 RES ARRAY 10K*8 9PIN 104
AN11 4355724604 WIRE 70MM(187) & 110MM(250) WIRE
AN9 4355923803 CONNECTOR WAFER 03P(J.ST) 3P
4448996911 FUSE DRAWER(31.8mm) 31.8mm
5508121337 FUSE 61S 31.8MM 300MA/250V U/C 300MA
4448996914 VOLTAGE SELECTOR 220V ONLY VOLT SELECTOR
4355753200 CON ASS'Y 1P 120MM MEQ-2000 CON 1P
4355753200 CON ASS'Y 1P 120MM MEQ-2000 CON 1P
4355736802 CON ASS'Y 1P-2P BLU 90MM CON 2P
4355736906 CON ASS'Y 1P-2P Y/G 130MM CON 2P
4458999110 FUSE CLIP 5*20 5*20
PCB 4005179300 PCB MAIN B'D PW-9242N PCB
RLY5 5528001040 RELAY RZ-24 RY24W DC24V RY24W
RLY4 5528001040 RELAY RZ-24 RY24W DC24V RY24W
RLY3 5528001040 RELAY RZ-24 RY24W DC24V RY24W
RLY2 5528001040 RELAY RZ-24 RY24W DC24V RY24W
RLY1 5528001040 RELAY RZ-24 RY24W DC24V RY24W
ELECTRICAL PARTS LIST
Ref No. Part No. ValueDescription
X1 3908101990 X-TAL 32.768KHZ GT-2190C X-TAL
SW15 4628098520 SW PUSH SPUN19X1M031 (SUI52) SW
RLY7 5528009950 RELAY HR-CR3A23 DC 24VH RELAY
RLY6 5528009950 RELAY HR-CR3A23 DC 24VH RELAY
R27 S30101037231 RES TF 10K 1/10W 2012 10K
R26 S30104737231 RES TF 47K 1/10W 2012 47K
R25 S30107507231 RES TF 75 1/10W 2012 75
R24 S30101037231 RES TF 10K 1/10W 2012 10K
R23 S30101037231 RES TF 10K 1/10W 2012 10K
R22 S30101037231 RES TF 10K 1/10W 2012 10K
R21 S30101037231 RES TF 10K 1/10W 2012 10K
R20 S30104737231 RES TF 47K 1/10W 2012 47K
R19 S30107507231 RES TF 75 1/10W 2012 75
R18 S30107527230 RES TF 7.5K J 1/10W 2012 7.5K
R17 S30104727231 RES TF 4.7K 1/10W 2012 4.7K
R16 S30101037231 RES TF 10K 1/10W 2012 10K
R15 S30101037231 RES TF 10K 1/10W 2012 10K
R14 S30101027231 RES TF 1K 1/10W 2012 1K
R13 S30101017231 RES TF 100 1/10W 2012 100
R12 S30104737231 RES TF 47K 1/10W 2012 47K
R11 S30101007451 RES TF 10 1/4W 3225 10
R10 S30101007231 RES TF 10 1/10W 2012 10
R9 S30101007231 RES TF 10 1/10W 2012 10
R8 S30101007231 RES TF 10 1/10W 2012 10
R7 S30101007231 RES TF 10 1/10W 2012 10
R6 S30101007231 RES TF 10 1/10W 2012 10
R5 S30101007231 RES TF 10 1/10W 2012 10
R4 S30101007231 RES TF 10 1/10W 2012 10
R3 S30101007231 RES TF 10 1/10W 2012 10
R2 S30101227231 RES TF 1.2K 1/10W 2012 1.2K
R1 S30101067230 RES TF 10M J 2012 10M
PT1 2828070710 TRANS POWER (225V)PW-9242V TRANS
OSC 3938100002 OSCILLATOR 11.592MHz HSL 11.0592MHz
L4 2648609600-T COIL INDUCTOR 10UH A03 10UH
L4 2648609600-T COIL INDUCTOR 10UH A03 10UH
L2 2648399890 INDUCTOR 330UH 330uH
L1 2648399890 INDUCTOR 330UH 330uH
JP1 4408194800 CON JUMP JUMPER/3PIN
JK10 4438094610 DC TERMINAL 2P DC 2P
IC23 2168640977 IC REGULATOR LM2575-12/LB03 LM12V
IC22 2168640978 IC REGULATOR LM2575-5/LB03 LM2575-5/5V
IC21 2118010590 IC NJM4558D JRC NJM 4558D
IC19 S21235405901 IC AM 29F0168 AMD IC AM 29F016B
IC18 S21274480001 IC MLC 1036 MCS LOGIC IC MLC 1036
IC17 2128514041 IC 74HC245 IC 74HC245
IC16 2128514039 IC 74HC574 IC 74HC574
IC15 2138000991 IC ULN2803 MOT IC UDN2803
IC14 2128514039 IC 74HC574 IC 74HC574
IC13 2138000991 IC ULN2803 MOT
IC ULN2803 MOT
IC12 2128514039 IC 74HC574 IC 74HC574
IC11 2128220000 IC UND 2981 ALLEGRO UDN 2981A
IC10 2128514039 IC 74HC574 IC 74HC574
IC9 2128514019 IC GD74HC32 G.S IC 74HC32
IC8 2128514021 IC GD74HC08 G.S IC 74HC08
IC7 2128720000 IC MAX232CPE IC MAX232
IC6 S21248320001 IC FM3808-70-T (RAMTRON) IC FM3808
IC5 2128514008 IC GD74HC138 G.S IC 74HC138
IC3 2128220600 IC DS 1232(DALLAS) IC DS1232
IC2 2128501016 IC 74HC573 IC 74HC573
IC1 2128110999 IC 89C52 IC 89C52
HS2 7505299340 HEAT SINK EQ-131 HEATSINK
HS1 7505299340 HEAT SINK EQ-131 HEATSINK
FT3 3908609970 EMI DSS6NZ82A103Q55B EMI
FT2 3908609970 EMI DSS6NZ82A103Q55B EMI
FT1 3908609970 EMI DSS6NZ82A103Q55B EMI
F2 5508121337 FUSE 61S 31.8MM 300MA/250V U/C 300MA
F1 5508111737 FUSE 51S 20MM 500MA/250V U/C 500MA
D28 S22401205005 KDS160-RTK KDS160
D22 S22401205005 KDS160-RTK KDS160
D21 S22401205005 KDS160-RTK KDS160
D20 S22401205005 KDS160-RTK KDS160
D19 2058100965 DIODE 1N5822 1N5822
D18 2058100965 DIODE 1N5822 1N5822
D17 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006
MAIN B’D (4005194300)
Ref No. Part No. ValueDescription
6
JACK B’D (4005179310)
