Inter-m SC-624 User Manual

2
ELECTRICAL PARTS LIST
Ref. Part No. Description Value
BK10 113478 BKT.PCB PS-M350 Bracket
BK6 113478 BKT.PCB PS-M350 Bracket
BK7 113478 BKT.PCB PS-M350 Bracket
BK8 113478 BKT.PCB PS-M350 Bracket
BK9 113478 BKT.PCB PS-M350 Bracket
BUZZER 112730 “BUZZER,CAP-1205SL(9.5),KEUM KANG” CAP-1205SL
C1 120352 “CAP,CE,MONO,COG,100PF,50V,J,2012,TA” 100P
C10 106012 “CAP,CE,MONO,X7R,1000PF,50V,K,RA,TA” 0.001U
C11 105807 “CAP,CE,MONO,0.1UF,50V,J,RA,TA” 0.1U
C12 106012 “CAP,CE,MONO,X7R,1000PF,50V,K,RA,TA” 0.001U
C13 105746 “CAP,CE,TEMP,NPO,15PF,50V,J,RA,TA” 15P
C14 105746 “CAP,CE,TEMP,NPO,15PF,50V,J,RA,TA” 15P
C15 105861 “CAP,FILM,POLYESTR,0.0047UF,100V,J,TA” 4700P100(M)
C16 105867 “CAP,FILM,POLYESTR,0.0056UF,100V,J,TA” 5600P100(M)
C17 106012 “CAP,CE,MONO,X7R,1000PF,50V,K,RA,TA” 0.001U
C18 106012 “CAP,CE,MONO,X7R,1000PF,50V,K,RA,TA” 0.001U
C19 105867 “CAP,FILM,POLYESTR,0.0056UF,100V,J,TA” 5600P100(M)
C2 105699 “CAP,CE,TEMP,SL,33PF,50V,J,RA,TA” 33P
C20 105861 “CAP,FILM,POLYESTR,0.0047UF,100V,J,TA” 4700P100(M)
C21 106012 “CAP,CE,MONO,X7R,1000PF,50V,K,RA,TA” 0.001U
C22 106012 “CAP,CE,MONO,X7R,1000PF,50V,K,RA,TA” 0.001U
C23 106012 “CAP,CE,MONO,X7R,1000PF,50V,K,RA,TA” 0.001U
C24 106012 “CAP,CE,MONO,X7R,1000PF,50V,K,RA,TA” 0.001U
C25 105746 “CAP,CE,TEMP,NPO,15PF,50V,J,RA,TA” 15P
C26 105835 “CAP,FILM,POLYESTR,0.015UF,100V,J,TA” 0.015/100(M)
C27 105935 “CAP,FILM,M-POLYESTR,SM,4700PF,100V,J,TA” 0.0047/50(M)
C28 106012 “CAP,CE,MONO,X7R,1000PF,50V,K,RA,TA” 0.001U
C29 106012 “CAP,CE,MONO,X7R,1000PF,50V,K,RA,TA” 0.001U
C3 106012 “CAP,CE,MONO,X7R,1000PF,50V,K,RA,TA” 0.001U
C30 105722 “CAP,CE,HI-DI,Y5P,680PF,50V,K,RA,TA” 680P
C31 105807 “CAP,CE,MONO,0.1UF,50V,J,RA,TA” 0.1U
C32 105807 “CAP,CE,MONO,0.1UF,50V,J,RA,TA” 0.1U
C33 105699 “CAP,CE,TEMP,SL,33PF,50V,J,RA,TA” 33P
C34 105699 “CAP,CE,TEMP,SL,33PF,50V,J,RA,TA” 33P
C35 106012 “CAP,CE,MONO,X7R,1000PF,50V,K,RA,TA” 0.001U
C36 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
C37 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
C38 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
C39 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
C4 105835 “CAP,FILM,POLYESTR,0.015UF,100V,J,TA” 0.015/100(M)
C40 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
C41 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
C42 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
C43 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
C44 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
C45 105807 “CAP,CE,MONO,0.1UF,50V,J,RA,TA” 0.1U
C46 105807 “CAP,CE,MONO,0.1UF,50V,J,RA,TA” 0.1U
C47 105807 “CAP,CE,MONO,0.1UF,50V,J,RA,TA” 0.1U
C48 105807 “CAP,CE,MONO,0.1UF,50V,J,RA,TA” 0.1U
C49 105807 “CAP,CE,MONO,0.1UF,50V,J,RA,TA” 0.1U
C5 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
C50 105807 “CAP,CE,MONO,0.1UF,50V,J,RA,TA” 0.1U
C51 105807 “CAP,CE,MONO,0.1UF,50V,J,RA,TA” 0.1U
C52 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
C53 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
C54 105671 “CAP,CE,HI-DI,Y5V,0.01UF,50V,Z,RA,TA” 0.01U
MAIN B’D
