load.UP Connector Board
Note: Do not refer to this illustration for touch.ON support; the boards are different and also require different
firmware
Dispenser
Printer
24V
+ -
Network
port 1
Network
port 2
Open collector
LED drivers
General
purpose
inputs
MDB
Coprocessor
reset
Connection
to main
board
Designates pin 1
Mag card
clock & data
Not currently used
LEDs
Blue – Bill MDB
Red – Coin MDB
Green – Credit Card
Yellow – Heartbeat
Green LED - Link
Yellow LED - activity
