English
Page 11
SET UP (continued)
5.
 Pressthebuttontoturnonthecontrolunitpanelbuttonsrst.
Pressthebuttontoinatethespatubwallfor8to10minutes
untilitisrmtothetouchbutnothard
(see drawing 6)
.
IMPORTANT:
Donotoverinateorusehighpressureair
compressortoinate.
6.
Press the button again to turn it off.
7.
Replace the air valve cap back.
NOTE:
The cap is designed to be screwed on and off. Never exert
forceasthiscouldcausethecompleteinternalinationsystemofthe
valve to come loose. See “Spa Tub Air Valve Fastening” for valve
maintenance.
Inate the Spa Cover Air Bladder
1.
 Opentheinationvalveandinserttheinationhose
(7)
into the
valve;presstoinateuntilitisrmtothetouchbutnothard
(see drawing 7)
.
2.
Disconnecttheinationhose
(7)
fromtheairblowerinationoutlet
and the valve.
3.
Replace the controlbaseination cap
(5)
back; close and recess
theinationvalve.
NOTE:
If there is a need to add some air to the spa tub wall or spa
coverairbladderaftertheyhavebeensetup,refertoabove“Inatethe
SpaTubWall”and“InatetheSpaCoverAirBladder”sections.Thecoverairbladderispreinstalledinside
thespacover.Ifitneedstobereinstalled,placetheuninatedairbladderinsidethespacoverlipbefore
inatingthebladder.
Deation
For Spa Tub Wall:
1.
Unscrew the cap to reveal the stem, push the stem in and turn 90
degree right to secure it in the down position
(see drawing 8)
.
2.
Oncethedeationiscompleted,pushthesteminandturn90degree
lefttoreturnittotheinationposition.
3.
Replace the cap back.
NOTE:
Todeatethespatubforstorage,see“STORAGE”section.
For Cover Air Bladder:
1.
 Pullvalvecapoutandsqueezethevalveatitsbaseuntildeated.
2.
Close and recess the valve back.
7
7
6
3
Press
4
5
7
5
7
1 2
8
2.
Press the button located on top of the control base and remove the back cover
(see drawing 3)
.
3.
 Unscrewthecontrolbaseinationcap
(5)
torevealtheairblowerinationoutlet,insertoneendofthe 
 inationhose
(7)
into the outlet and turn to the right to lock it
(see drawing 4)
.
4.
 Unscrewtheairvalvecaptorevealthestemintheuppositionforination.Inserttheotherendofthe 
 inationhose
(7)
into the valve and turn to the right to lock it in position
(see drawing 5)
.
