When ordering parts, be sure to quote the model number and part numbers.
PARTS (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
REF.
NO.
DESCRIPTION QTY.
P A R T N O .
4 ADULTS 6 ADULTS
28404 28406 28474 28408 28410
1 CONTROL BASE 1 12320 12320B 12320 12320 12320B
2 CONTROL BASE BACK COVER 1 11719 11719B 11719 11719 11719B
3 CONTROL PANEL (INCLUDED #4) 1 11930 11930B 11930 11930 11930B
4 CONTROL PANEL BOLT 3 11024 11024B 11024 11024 11024B
5 CONTROL BASE INFLATION CAP 1 11831 11831B 11831 11831 11831B
6 CONTROL PANEL BOLT WRENCH 1 11053 11053 11053 11053 11053
7 SPA/COVER INFLATION HOSE 1 11830 11830 11830 11830 11830
8 SPA CONTROL INLET/OUTLET O-RING 2 11699 11699 11699 11699 11699
9 SPA CONTROL AIR INLET O-RING 1 11687 11687 11687 11687 11687
10 SPA DRAIN PLUG 1 11696 11696B 11696 11696 11696B
11 SPA DRAIN VALVE ADAPTOR 1 11718 11718 11718 11718 11718
12 FILTER CARTRIDGE HOUSING 1 11798 11798 11798 11798 11798
13 FILTER CARTRIDGE 2 11692 11692 11692 11692 11692
14 FILTER CARTRIDGE HOUSING LID 1 11797 11797 11797 11797 11797
15 INLET/OUTLET PLUG 3 11739 11739 11739 11739 11739
16 SPA TUB 1 11842 12260 11842 12106 12258
17 SPA COVER 1 11841 12261 12752 12107 12256
18 SPA COVER INFLATABLE BLADDER (PRE-INSTALLED IN SPA COVER) 1 11689 11689 12753 12108 12108
19 GROUND CLOTH 1 11717 11717 11717 12109 12109
20 CHEMICAL DISPENSER 1
12735 12735 12735 12735 12735
21 TEST STRIPS 1 11855 11855 11855 11855 11855
22 WRENCH 1 11742 11742 11742 11742 11742
23 AIR PRESSURE RELEASE VALVE CORE 1 12589 12589B 12589 12589 12589B
24 INFLATION HOSE ADAPTOR 1 11829 11829 11829 11829 11829
25 MALE BUCKLE 6 11698 11698B 11698 11698 11698B
26 FEMALE BUCKLE 6 11799 11799B 11799 11799 11799B
27 DEFLATION OUTLET CAP 1 11934 11934B 11934 11934 11934B
28 DEFLATION HOSE ADAPTOR 1 11935 11935 11935 11935 11935
29
SPA FILTER MOTOR
1 11886 11886B 11886 11886 11886B
