(333IO) 42” LADDER WITH REMOVABLE STEPS ENGLISH SIZE: 7.5” X 10.3” PANTONE 295U 08/16/2017
Page 7
4. U-SHAPED TOP RAIL INSTALLATION
(refer to figures 4.1 through 4.2):
IMPORTANT:
Make sure the “top brace with locking system” (3) feature is facing
outward (your right side when facing the C legs assembly).
5. SIDE A & B LEGS INSTALLATION
(refer to figure 5):
IMPORTANT:
Do not fully tighten fasterners until last assembly operation
3.4
C
C
17 (M6*35)
3.3
C
C
C
C
18
14
LADDER SETUP (continued)
4.2
17 (M6*35 )
17 (M6*35)
12525
12524
4.1
5 (M6*45)
16 (M6*40)
12524
12525
17 (
M6*35)
5
1
3
2
