Intex BM4212 User Manual

(173PO) 12 VOLT TROLLING MOTOR ENGLISH 7.5” X 10.3” 05/21/2012
173
PO
SAVE THESE INSTRUCTIONS
Page 2
173
PO
Tilt / twist / tiller
extension handle
Battery meter & Weed
escape control button
Control box
Clamp screws

Motor
Propeller
Tilt lock lever
Multi-position
mounting bracket
Quick release depth collar /
steering tension knob
SETUP INSTRUCTIONS
Mounting

CAUTION: Over-tightening the clamp screws can damage the motor mounting bracket.
Tilt Lock lever
teering tension knob
Clamp screws
Quick release depth collar / lever arm

appearance, which may result in updates to the instruction manual, without notice.
Overview:

Intex BM4212 Specifications

General

Product type	Outboard motor
Shaft length	914 mm
Product color	Black
Maximum thrust	180 N
Brand compatibility	-
Maximum motor power	420 W
Number of forward gears	5
Number of reverse gears	3
Recommended boat weight	909 kg
Number of propeller blades	2
Battery voltage	12 V
Current consumption (max)	35 A
Package depth	460 mm
Package width	1200 mm
Package height	230 mm
Package weight	11080 g
