Invacare Ranger II Basic - Page 43

43
PROCEDURE 12BATTERIES
B
A
T
T
E
R
I
E
S
FIGURE 3 - CONNECTING BATTERY CABLES - DIRECT MOUNT METHOD
Orange Battery
Terminal Cap
POSITIVE
(+) Battery
Terminal/
Post
U-1
Battery
Gray
Battery
Terminal
Cap
Tie-
Wrap
NEGATIVE
(-) Battery
Terminal/
Post
Tie-
Wrap
1/4-20
Hex
Flange
Locknut
Negative (-)
Battery Terminal/
Post
1/4-20 x 7/8-Inch
Hex Flange Screw
Positive (+) Battery
Terminal/Post
U1
Battery
1/4-20 x 7/8-Inch
Hex Flange Screw
NEGATIVE (-) Battery
Terminal/Post
Group 22NF
Battery
POSITIVE (+) Battery Terminal/Post
POSITIVE (+) Red
Battery Cable
NEGATIVE (-)
Black Battery
Cable
DETAIL “B”
1/4-20
Hex
Flange
Locknut
CONNECT BATTERY
CABLE TO BATTERY
TERMINAL AS SHOWN.
DUAL U1 BATTERIES
BLACK BatteryTerminal
Cap
POSITIVE
(+) Battery
Terminal/
Post
Group 22 NF
Battery
RED
Battery
Terminal
Cap
Tie-
Wrap
NEGATIVE
(-) Battery
Terminal/
Post
Tie-
Wrap
DETAIL “A”
DUAL GROUP 22 NF BATTERIES
CONNECT
BATTERY
CABLE(S) RING
TERMINAL(S) TO
THIS SIDE OF
BATTERY
TERMINAL(S)/
POST(S)
DUAL U1 BATTERIES
DUAL GROUP 22 NF BATTERIES
