58
FIGURE 19 - REPLACING WIRING HARNESS - 14-INCH WIDE MODELS
Left Hand Motor and
Controller Connection
Battery Wiring Harness
and Controller Connection
(BLUE)
Wire Connector Support
MKIV
Controller
Slot
Charger Cable
Mounting Bracket
Wiring
Harness
To Controller
Phillips Screws
Locknuts
Phillips Screws
Tie-Wrap
Phillips Bolts
Spacer
Spacer
Rear Battery
Connector
Front Battery
Connector
Right Hand Motor and
Controller Connection
F
W
D
W
H
E
E
L
C
H
A
I
R
S
PROCEDURE 13 FWD WHEELCHAIRS
