SPECIFICATIONS
NOTE: All specifications
are approximate.
RANGER II FWD - R2
JR
INTEGRATED SLING SEAT
Seat Width Range: 14-inches
Seat Depth Range: 16 to 18-inches - In 1-inch increments (17 and 18-inch by extension)
Back Height Range: 16 to 20-inches - In 1-inch increments
Back Angle Range: 90
o
to 105
o
- in 5
o
increments
Seat-to-Floor: 18-1/2-inches
Overall Width
(No joystick): 20-5/8-inches
Overall Height: 34-3/8-inches - 16-inch Back Height
Overall Length L REAR DRIVE POSITION
With 8-inch rear casters
and 93 front riggings: 43-1/2-inches
With 8-inch rear casters
and no front riggings: 32-1/2-inches
L
NOTE: Refer to PERCENTAGE OF WEIGHT DISTRIBUTION in
PROCEDURE 1 of this manual.
Drive Wheels/Tires 12-1/2 X 2-1/4-inch (Pneumatic-Standard, Flat Free - Optional)
Caster w/Precision
Sealed Bearings: 8 x 1-3/4-inch Semi Pneumatic (Std.), 8 x 2-inch Pneumatic (Opt.)
6 x 2-inch Semi Pneumatic (Opt.)
Footrests/Legrests: Swingaway, Removable
Weight
1
W/O Batteries: 83 lbs.
W/Batteries (Gel Cell): 153 lbs.
Shipping: 98 lbs.
Armrests: Removable, Flip Back, Fixed or Adjustable Height - Desk and Full Length
Upholstery: Black Nylon
Batteries: U1 Gel Cell
PERFORMANCE
Speed (M.P.H.): 0 to 3.6
Turning Radius: 24-inches
Range (variable)
2
: 14 miles
L Weight Limitation
3
: 200 lbs.
L
NOTE: Refer to PERCENTAGE OF WEIGHT DISTRIBUTION in PROCEDURE 1 of this manual.
Footnotes:
1. 14-in. wide x 16-in. deep wheelchair with MKIV RII electronics.
2. Range will vary with battery conditions, surface, terrain and operators weight.
3. Includes seating systems and accessories.
