inventiv INV E2046 T - Page 51

51
Parts Description
1
1a
7
8
9
10
11
12
13
14
1516
18 19
2
3
4
5
617
1. Switch box
1a.--Switch button
2. Quick release lock
3. Rear ap
4. Height adjustment handle
5. Front carrying handle
6. Drive control bar
7. Grip handle
8. Switch bar
9. Cable tension bolt kit
10. Upper handle
11. Plug and cord
12. Lower handle
13. Grass bag
14. Bolts (M8X16) and nuts (M8) for
lower handle assembly
15. Motor
16. Deck
17. Cord strain relief
18. Wrench
19. Mulch kit
