Wheel Drive
Adjusting the Bowden cable
If the wheel drive can no longer be switched on or o while the motor is running, the
related Bowden cable needs to be adjusted.
How to adjust the Bowden cable tension bolt kit:
• Loosen the locking nut (1).
• Hold the locking nut (1) and turn the stop nut (2) clockwise to shorten the cable,
counterclockwise to lengthen the cable.
• Tighten the locking nut (1) once the self-propelled function is working properly.
• To test the cable setting, switch on the motor and switch on the wheel drive.
• If the wheel drive is still not working, the lawnmower must be taken to a service
point or an authorized specialist.
Repair
This product does not contain any parts that can be repaired by the consumer.
Contact an authorized service centre or a similary qualied person to have it checked
and repaired.
WARNING! Adjust the Bowden cable only when the motor
is switched o.
