inventum IKI6021 - Installation Dimensions

590
560
53
520
490
min. 25*
min. 25*
* 40mm when the neighbouring walls
are wood.
INSTALLATION DIMENSIONS
In the drawings below, all the dimenions are displayed in mm. Make sure you use the right drawing for the model you have.
IKI6020 - IKI6021 - IKI6022 - IKI6023
890
860
53
490
520
min. 40**
min. 25*
* 60mm when using a back of wood.
** 150mm when using a sidewall of
wood.
IKI9021
780
750
53
490
520
min. 40**
min. 25*
* 60mm when using a back of wood.
** 150mm when using a sidewall of
wood.
IKI7821
English • 31
