inventum IPF800R - Operation; Technical Data

Connecting the filter
1. Connect the extractor hood plug and the filter plug to the mains adapter.
2.
Connect the mains adapter to the mains supply.
Finishing the installation
1. Install the shaft on the extractor hood.
2. Make sure that the shaft has sufficient openings for ventilation.
5 Operation
PREPARING FOR OPERATION
1.
For optimal room air cleaning, it is imperative for your extractor hood to be adequately ventilated and adapted
to the respective steam development.
2.
Make sure that you activate your extractor hood at level 1 or 2 at least 10 minutes before you start cooking.
COMPLETING OPERATION
1. Make sure that your extractor hood operates at level 1 or 2 for 15 minutes after you finish cooking.
6 Technical data
PRODUCT FICHE
Item Specification
Capacity 800 m
3
Features Suitable for all extractor hoods (new / pre-installed)
Cleaning the air and removing bad odours up to 98%
Long lifespan
Self cleaning
No ozone O
3
Double filter: plasma and carbon
Compliant to RoHS directive
Pressure loss 100 Pa per 2 m/s
Contact time / Inflow speed depending on level of contamination
0.1-1 sec., max. 2 minutes
Noise level 0 dB
DIMENSIONS AND MASS
Item Specification
Diameter [mm] 210
Height [mm] 210
Diameter connection [mm] 150
Gross weight [kg] 2.7
Net weight [kg] 1.66
(Figure 7)
EN • 15
