Regulation controls:
Systematically use the tool supplied with the appliance to operate the controls which can be very hot.
 Firing rate control: this control is used to modulate the appliance firing rate between “normal rate” and “slow combustion’. Once the
appliance is lit, do not go further than the ”normal firing rate position corresponding to a 30 % opening.
 Lighting control: Using the firing rate control beyond the “normal firing rate” position provides additional air for lighting. This position is
reserved for lighting and re-starting operations and must not be used for more than 30 minutes as this may cause damage to the appliance and
its surroundings. The appliance must be kept under surveillance the entire time this position is used.
Lighting fully open
Normal firing
rate 30% open
Slow firing
rate fully closed
