Wood stove REMILLY Référence: P601384
Code 1
XD, le 22/06/2021 Page 17 of 18
Deflector assembly
It is compulsory to fit the deflector before the wood burner is commissioned.
- Cut the ink between the deflector and the grate.
- Fit the deflector vertically in the appliance along the A bossing.
- Place it on the A bossing, sloping it towards the back of the appliance.
- Let is slide along the 1 bossing and place onto the B bossing.
